Understanding 10k Resistor Color Code
Resistors are an important part of any electronic circuit. They are used to control the flow of current and can be used to regulate the voltage in a circuit. In order to identify the value of a resistor, it is important to know the resistor color code.
What is 10k Resistor Color Code?
A 10k resistor color code is an identification system used for identifying the value of a resistor in the circuit. It consists of four colored bands, each of which has a specific meaning. The colors used in the resistor color code are black, brown, red, orange, yellow, green, blue, violet, gray, and white.
How to Read 10k Resistor Color Code?
Reading the resistor color code is a simple process that involves looking at the colors of the four bands. The first two bands represent the first two significant figures of the resistor's value, while the third and fourth bands represent the number of zeros following the first two significant figures. The first band is the first significant figure, the second band is the second significant figure, the third band is the number of zeros, and the fourth band is the tolerance.
10k Resistor Color Code Table:
The following table gives the 10k resistor color code for the first two significant figures and the number of zeros following them.
| Significant Figures | Color | Number of Zeros | Color |
|---|---|---|---|
| 10 | Brown | 3 | Orange |
| 20 | Red | 2 | Red |
| 30 | Orange | 1 | Yellow |
| 40 | Yellow | 0 | Green |
The tolerance of 10k resistor color code is usually represented by a gold or silver band. The gold band indicates that the resistor has a tolerance of ± 5%, while the silver band indicates that the resistor has a tolerance of ± 10%.
